PICMG Ratifies MicroSAM – The New Microcontroller-Agnostic Module Form Factor for the Enablement of Smart Sensors
PICMG, a leading consortium for the development of open embedded computing specifications, announces the ratification of the MicroSAM specification. MicroSAM is a new microcontroller-agnostic, ultra-small form-factor module for the enablement of smart sensors.
MicroSAM is the first PICMG specification in a series of IIoT-related open standards to reach ratification. It is the only open hardware specification to date that addresses the fast-growing sensor market. MicroSAM enables a fundamentally different IIoT architecture, offering a distributed architecture with true Plug and Play network integration. The specification defines a 32mm x 32mm module hardware platform for traditional sensor vendors wishing to quickly create smart sensors.
“I would liken the impact of this specification on the IIoT market to that of the Open Compute Project on the data center space”, said Doug Sandy, Chief Technical Officer, PICMG. “When combined with the PICMG sensor domain network architecture and data model, sensors will seamlessly integrate into the network with plug-and-play interoperability”, he continued.
MicroSAM fills a need not currently addressed by other industry specifications; namely, a compact module targeted at microcontrollers for each of the Industrial IoT sensor nodes. The processing performance and I/O connectivity are targeted toward the sensor interface. MicroSAM may exist in parallel with other embedded technologies, where MicroSAM devices provide sensor connectivity, and PICMG standards such as COM Express®, CompactPCI® Serial or MicroTCA® provide higher layers of control.
Jessica Isquith, president of PICMG, adds “this specification has the potential to accelerate the shift to better sensor interoperability and encourage a better and wider range of options.”
Other specification work includes requirements for common firmware features, common data model, network architecture, and integration with the Distributed Management Task Force’s (DMTF) Redfish management API.
PICMG developed this specification to benefit the industry in three specific ways:
- It will enable sensor vendors to create smart sensors without having to manufacture the control circuitry and/or software by purchasing these components from PICMG-compliant suppliers.
- It will enable controller suppliers who wish to create smart sensors or smart-sensor components to do so in a way that is interoperable with other suppliers.
- Accelerate the uptake of smart-sensor technology through open-specifications and interoperability.
MicroSAM was developed in collaboration with the following PICMG members: ADLINK Technology Inc., AMI USA Holdings Inc., Arroyo Technology, Avnet Integrated, Elma Electronic, ept, Intel, Lodz University of Technology, nVent, Samtec, TE Connectivity, Trenz Electronic, and Triple Ring Technologies.
MicroSAM extends and co-exists with the existing open-sourced microcontroller ecosystem by offering a standards-based solution that has been designed specifically for embedded use.
Some of its key technical advantages are:
- Full industrial operating temperature range
- Small size (32mm x 32mm)
- Low power consumption
- Power filtering and signal conditioning for embedded installations
- Reliable industrial-grade communications
- Direct connectivity to a variety of sensor types (analog voltage, analog current, digital)
- Latching connectors for secure connectivity
- PWM output for motion control applications
