Advantech launches the UNO-2484V3 edge computer for industrial automation.

The industrial automation landscape requires hardware platforms capable of handling complex computational workloads directly at the field level. Advantech addressed this need by introducing the fanless edge computer UNO-2484V3, designed to operate in harsh industrial environments and support data-intensive applications such as computer vision and predictive maintenance. The industry trade show took place in Eindhoven, Netherlands, on September 7, 2026. The technology integrates into the context of digital transformation and Industrial Edge infrastructure, providing manufacturers with advanced tools for local data processing and edge-to-cloud connectivity.

Architectural specifications and computing performance
The system adopts Intel Core Ultra (Series 2) 5 and 7 processors (Arrow Lake-U, 15 W), configured with a maximum of 14 CPU cores and a 12 MB L3 cache. The hardware architecture integrates dual-channel DDR5-6400 memory via two SO-DIMM slots, supporting up to 64 GB of capacity. Compared to previous models based on 11th Generation Intel Core processors and DDR4 memory, the adoption of the new platform reduces computational response times and increases multi-protocol processing capacity. Platform security is handled by the integrated TPM 2.0 chip, which ensures hardware-level process integrity.

Connectivity and expansion flexibility
The industrial I/O configuration includes one GbE LAN port based on the Intel i219 controller and three 2.5GbE LAN ports based on the Intel i226 controller. For serial and peripheral communication, four RS-232/422/485 ports, three USB 3.2 Type-A ports, and two USB Type-C ports are available. Video stream management supports up to four independent displays via one HDMI 1.4 port, one DisplayPort++, and two USB Type-C outputs. Modularity is guaranteed by four M.2 slots (one B-key, one E-key, and two M-key) and an externally accessible nano SIM card slot. A second optional stack allows the installation of two replaceable 2.5-inch SSDs and the integration of Advantech iDoor expansion modules for fieldbuses and wireless connectivity.

Mechanical reliability and field operability
Built within the UNO-2000 V3 series, the device adopts a compact form factor with dimensions of 200 × 140 × 55 mm and a solid-state fanless design. Thermal management is handled by an optimized heat sink. The system operates with an input voltage range between 10 and 36 VDC and supports operating temperatures from −20 °C to 60 °C. The hardware user interface includes dedicated LEDs for PWR, RUN, and BAT status, alongside a removable DIMM cover that facilitates maintenance and memory upgrades in the field. On the software front, the platform ensures compatibility with Windows 11 LTSC and Advantech EdgeLinux operating systems.

Additional Context:
This section details technical specifications and competitive benchmarking not included in the original product announcement

This section outlines the detailed technical specifications and competitive positioning of the UNO-2484V3 edge computer within the industrial automation segment. In the market for fanless industrial computers based on low-power architectures (15 W), direct competitors include solutions based on equivalent embedded platforms, such as the Nuvo series systems from Neousys Technology and the SIMATIC IPC series from Siemens.

From a computing performance perspective, the integration of Intel Core Ultra (Series 2) processors with a 14-core architecture and DDR5-6400 memory delivers an estimated memory bandwidth increase of 30% to 50% compared to standard platforms utilizing DDR4 operating at 3200 MT/s. The network infrastructure benefits from the triple presence of native 2.5GbE interfaces, exceeding the common standard of two ports found on many competing devices of identical format (200 × 140 mm).

The presence of four M.2 slots distributed across different keys (B, E, M) offers superior flexibility for the simultaneous housing of 5G/LTE cellular communication modules, Wi-Fi modules, and high-speed NVMe storage drives, overcoming the typical limitations of industrial systems bound to legacy mPCIe slots or single combined slots. The modular design with an optional stack for 2.5-inch SSDs and iDoor modules positions Advantech's platform as a versatile solution for high-density data acquisition in complex environments, although direct comparison heavily depends on specific industrial certifications and the customization requirements of each individual production facility.

Edited by Sucithra Mani, Induportals editor – adapted by AI.

www.advantech.com
